SPECIFICATIONS

Brand Name: NoEnName_Null

Origin: Mainland China

Power Source: Lithium Battery

Power Supply: Lithium Battery

Voltage: 48V

[DESCRIPTION]

[/DESCRIPTION][SPECIFICATIONS]

General

• Brand: COSWHEEL

• Model: T16

• Type: Electric MotorBike

• Color: White

Specifications

• Top Speed: Class 2/3, 28 Mph (45Km/h)

• Range: 40+miles (64km) in Class-2 throttle-only mode (pure electricity); 70+miles (113km) in Class-1 PAS (pedal assist)

• Motor: 48V Peak 1000W (Rated 750W) Brushless Rear Hub Motor 50N.m

• Battery: 48V 20Ah Battery (Lithium 18650 Cells)

• Energy: 960Wh

• Front Suspension: Single-shoulder shock-absorbing front fork 16 inches * 4.0 * 135mm \ total height 385mm \ toothless riser length 215mm, 80mm Travel

• Rear Suspension: 3000 Pounds, 170mm Travel

• Brakes: Double Piston Oil Brake, Equipped with 180mm Stainless Brake Disc

• Tires: ChaoYang All Terrain Tire 16" × 4.0" H5176 30TPI

• Throttle: Grip Twist Throttle

• Charger: 48V3A Charger

• Charging Time: 3.5-8.0 Hours

• Display: Easy Read LCD Display, Equipped with UDE remote control + 2 NFC cards

• Controller: 48V 22A

• Front Light: Round retro headlights with daytime running lights

• Rear Light: LED

• Pedal Assist: 3 Levels

• Sensors: Speed Sensor

• Frame: Hydroformed Triple-Butted 6061-T6 Aluminium Alloy

• Pedal: Aluminum Alloy Pedal, with Reflect-light, Axis 9/16 x2

• Crank: 1/2 "*3/32"*46T 7-speed ED Tooth Plate

• Rear Derailleur: Shimano 7-Speed

• Chain: 7-speed Anti-rust, 1/2" * 3/32"

• Handlebars: HB-B072\25.4*L:640mm*H:180mm\17°\middle horizontal φ22.2*H:140mm\sandblasting black

• Suitable Height: 4'11" - 5'11" (4.9ft-5.9ft)

• Seat Height: 29.53" (75cm)

• Bike Height: 39.37" (100cm)

• Wheelbase: 38.58" (98cm)

• Handlebar Width: 25.59" (65cm)

• Bike Weight: ≥97lbs (with Battery) (≥44kg)

• Maximum Load: 330lbs (150kg)

• Safe Load: 265lbs (120kg)

• Overall Size: 60.24" * 25.59" *39.37" (153*65*100cm)

• Package Size: 55.91" * 12.60" * 32.28" (142*32*82cm)

Package Contents

• 1 x Electric Bike

• 2 x Fender

• 1 x Charger

• 1 x User Manual


• 1 x Tool Bag
